MDR-OE-05 微气象智能监测终端

    微气象智能监测终端，是一款集成了多种传感器可选配的智能监测终端，可选配的传感器包括：大气温度传感器，大气湿度传感器,大气压传感器,风速传感器,风向传感器,噪声传感器,光照度传感器,PM2.5传感器,PM10传感器,土壤温度传感器,土壤湿度传感器,土壤PH值传感器,降雨量传感器，共13种。支持无线NBIOT传输方式。支持COAP,UDP,TCP,LWM2M多种通信协议。
        该产品支持外接电源供电及太阳能电池板供电，内部集成大容量电池，适用于野外、供电不便的使用场景。产品采样传感器和采集器分离式设计，方便安装和配置接入多种不同传感器，可满足建筑工地，农业种植，城市街道，野外科考，校园教育等多种场景小型气象环境监测需求。

        Micrometeorological intelligent monitoring terminal is an intelligent monitoring terminal that integrates a variety of optional sensors, optional sensors include: Atmospheric temperature sensor, atmospheric humidity sensor, atmospheric pressure sensor, wind speed sensor, wind direction sensor, noise sensor, illumination sensor,PM2.5 sensor,PM10 sensor, soil temperature sensor, soil moisture sensor, soil PH sensor, rainfall sensor, a total of 13 kinds. Support wireless NBIOT transmission mode. Support COAP,UDP,TCP,LWM2M multiple communication protocols.

        The product supports external power supply and solar panel power supply, and integrates large-capacity batteries inside, which is suitable for field and inconvenient power supply scenarios. Product sampling sensor and collector separate design, easy to install and configure access to a variety of different sensors, can meet the construction site, agricultural planting, urban streets, field research, campus education and other scenarios of small meteorological environment monitoring needs.

工作原理/Working principle

        采用控制器和传感器分立设计，控制器通过RS485连接多个传感器，定时采样传感器数据（采样时间可调），采样后将数据按照定时上报间隔发送微气象采集数据到云平台。

        Discrete design of the controller and sensor, the controller connects multiple sensors over RS485, periodically samples sensor data (sampling time is adjustable), and sends the data to the cloud platform according to the periodic reporting interval.
